Atoll DAC300

Atoll DAC 300 |

The DAC300 DAC Atoll is equipped with an ESS Sober 9038PRO converter and can process digital audio signals up to 32 bits and 768 kHz.

The French brand Atoll offers with the DAC300 an uncompromising digital-to-analog converter, equipped with S / PDIF optical, coaxial and AES / EBU inputs, as well as a USB type B port. The Atac DAC300 DAC is distinguished by a neat design, which implements a dual power supply - for digital and analog circuits - to reduce interference. The balanced output stages employ discrete components while the audio links use high quality MKP capacitors. This DAC also has a very good quality of manufacture, with a thick steel frame and a brushed aluminum front.

The DAC300 Atoll DAC is an audiophile solution for using digital audio files from a computer, including studio-quality up to 32-bit and 768-kHz. Its asynchronous USB port, coupled with a powerful internal synchronization clock, helps reduce the distortion of the streamed digital stream. Ideally, such a DAC should be used with software compatible with the ASIO protocol (Foobar2000 on Windows and Audirvana on Mac OS).

Atoll DAC 300 Technical Data

ESS Saber 9038Pro with SABER ES9311EQ power supply
Two independent toroidal transformers
12 independent voltage regulators
Discrete and non-feedback component output stages, polarized in class A
MKP capacitors
32-bit / 768 kHz USB controller
24-bit / 192kHz S/PDIF controller
Variable level outputs
Remote control

Measurements
Signal-to-noise ratio: 137 dB

Connectors<
3x optical S / PDIF inputs To slink and 1x output
3x RCA coaxial S / PDIF inputs and 1x output
1x AES / EBU input
1x USB type B input
1x stereo RCA output
1x stereo XLR output
1x headphone output

Minimum consumption: 0.44 W (low mode) - 13.1 W
Maximum consumption: 13.6 W
Dimensions (WxHxD): 440 x 60 x 280 mm
Weight: 4 kg
